How to get rid of MacOS’ “one or more items can’t be changed because they are in use”

No CommentsMacOS, The Hackererby Axel Dietrich

Sometimes MacOS locks files and you cannot copy, move, or delete them. Here is how to get rid of this "one or more items can't be changed because they are in use" behaviour.

MacOS can be annoying, at times. In this case I was struggling with a video file that could not be copied, moved, or deleted because MacOS persistet on telling me it “can’t be changed because [it is] in use”; cf. this screenshot of the popup message.

The Continue-Button might suggest that MacOS would perform the action if I clicked it. But after clicking continue, I was asked for my admin-password, the file would seemingly get copied (or moved etc.), and finally, the copied (or moved file etc.) would be deleted.

It took a lot of searching until I, finally, came across the solution in this thread. I did not dig into the gory details of the cause but it has something to do with the so-called extended file attributes. You can see if a file has extended file attributes when you do a ls in the terminal. If there is an @ on the right-hand side of the file permissions this file has extended attributes set. As was the case with my video file:

> ls
-rwxr-xr-x@ 1 zzz  staff  42164199 Dec 19 18:58 MAH07541.MP4

Using the -l@ flag we can see the extended attributes that are set for the file:

> ls -l@
-rwxr-xr-x@ 1 zzz  staff  42164199 Dec 19 18:58 MAH07541.MP4
	com.apple.FinderInfo	      32

So in my case it’s the com.apple.FinderInfo attribute that was causing the problem. As soon as I deleted the extended attribute using

> xattr -d com.apple.FinderInfo MAH07541.MP4

everything was back to normal and the file could be copied, moved, or deleted.

Be careful when you are fiddling with the extended attributes since they can also store resources or essential file metadata. A user in the above mentioned thread says that it is “…always safe to delete com.apple.FinderInfo”. Well, that is something you will have to decide on your own.

How to restart iPhone 8 (Plus|X) when you can’t shut down

No CommentsThe Hackererby Axel Dietrich

How to force-reboot an iPhone 8 (Plus|X) that acts weird? We show the new three steps to reboot since the process has changed from previous iPhone versions.

The process of restarting your iPhone has changed with the advent of the iPhone 8, iPhone 8 Plus or iPhone X.
Such a restart, or hard reset, is necessary if your iPhone is acting weird like you are not able to shut it down by long pressing the side button or you can’t start apps etc.

The force-reboot is no longer achieved by pressing the side and home button simultaneously. Now you have to use the following sequence:

Press the volume up button once.
Press the volume down button once.
Press and hold the side button until the Apple logo appears (approx. ten seconds).

That’s it, your iPhone should reboot. In case you protect your iPhone using a PIN, which is recommended, you will have to enter your PIN after reboot.

Webhosting (nicht nur) für echte Kommandozeilen-Nerds

No CommentsBla Bla Blaby Axel Dietrich

Viele große und auch kleine Webhosting Massenanbieter haben gewisse Herausforderungen. Hier (m)eine Lobeshymne auf die große Ausnahme "uberspace".

Ich hab’ sie alle durch, die Massen-Web-Hosting-Anbieter. Eine nicht vollständige Liste in zufälliger Reihenfolge: Host Europe, all-inkl, Strato, Hetzner, alfashosting, goneo, GoDaddy, Celeros usw. usf. Das könnte ein langer, langer, geradezu ausgesprochen langer Rant darüber werden, was in schöner Regelmässigkeit bei denen alles nicht funktioniert bzw. funktioniert hat. Aber da muß jeder seine eigenen Erfahrungen machen. Und es ist auch gar nicht auszuschließen, dass jeder der genannten Dienstleister seine passende Zielgruppe hat, für die alles, sagen wir mal, irgendwie und gefühlt läuft.

Für mich war jeder Webhoster-Wechsel immer mit der Hoffnung verbunden, nun jemanden gefunden zu haben, der sein Geschäft im Griff hat. Aber eigentlich gab es immer nur Variationen der bekannten Ärgernisse: Support mit durchwachsener Fachkenntnis, träge Reaktionszeiten, Standardformulierungen, Geschwindigkeitsprobleme und Security Issues. Gerade der letzte Hoster setzt mit seiner technischen Inkompetenz insbesondere im Bereich des Server Hardenings dem ganzen noch einmal eine unrühmliche Krone auf. Der Name sei nicht genannt denn hier soll niemand diskreditiert werden.

Ganz im Gegenteil: Ich möchte hier einen Webhosting-Anbieter hervorheben, nein, geradezu anpreisen, der mir über die letzten zwei Jahre extrem an’s Herz gewachsen ist. Und das nicht, weil ich besonders oft den Support gebraucht hätte. Das war nur einmal der Fall und es gab innerhalb von Minuten eine fachlich extrem versierte Antwort, die konkret auf mein Anliegen einging und sofort weiterhalf. Das allein hat beim Martyrium aus IVRs, bestenfalls halb gelesenen E-Mails und Antworten, die dann nur noch auf ein Viertel des ursprünglichen Anliegens eingehen, schon extremen Seltenheitswert.

Katze aus dem Sack: Es geht um uberspace.de. Aus meiner Sicht kein klassischer One-Klick-To-Happiness-Webhoster mit Klicki-Bunti-GUI, sondern eher was für technikaffine Maker, die den Umgang mit der Kommandozeile nicht scheuen. Man muß sicher kein Web-Guru oder Un*x-Admin sein, aber schonmal in der Shell gearbeitet zu arbeiten, hilft sicherlich bei der Einrichtung des eigenen Web-Space. Allein daran sieht man schon, dass uberspace irgendwie … anders ist. Positiv anders.

Ein anderes Beispiel: Wer auf der Kommandozeile seine Domains, Mail-User oder den SpamAssassin verwalten möchte, der braucht eine Dokumentation. Die gibt es in Form eines umfangreichen WIKIs, das meiner Meinung nach kaum Wünsche offen lässt. Und noch etwas fällt sofort auf, wenn man das WIKI oder auch die Webseite durchliest: Kompetenz pur. Und Überzeugung. Beispielsweise, was die Preise/Bezahlung anbelangt. Jeder entscheidet selber, wieviel er uberspace bezahlen möchte. Auch die Abhandlungen über den Verzicht auf die Lastschrift (bezahlt wird per Überweisung) oder ganz generell immer wieder die Erläuterungen, warum das Team von uberspace die Dinge so macht, wie sie sie machen, sind absolut lesenswert.

Es gibt kaum eine Text, eine Erläuterung oder sonst eine Stelle, an der ich nicht einen Haken machen könnte. Selbst im gerade durchforsteten Impressum gibt es wieder etwas, wovon sich andere Seitenbetreiber etwas abschneiden könnten. Die meisten klicken sich ihren Impressums-Sermon bei erecht24 oder sonst wo zusammen und klatschen dann diesen Text mit mehr oder weniger Verstand auf ihre Seite. Bei uberspace finden wir aber: “[…] In Sachen Linkhaftung sparen wir uns den sonst üblichen Disclaimer, der nach Meinung der meisten Juristen ohnehin keine Rechtswirksamkeit entfaltet. […]” Ita est!

Ich bin schlichtweg begeistert von uberspace und wünsche mir inständig, dass sie im Rahmen der eigenen Ansprüche und Wünsche prosperieren und damit allen, die einen wirklich richtig guten Webhosting-Dienstleister haben möchten, lange erhalten bleiben!

I18n: nullseite.de goes zeropage.io

No CommentsBla Bla Blaby Axel Dietrich

Not really a matter of internationalization but the Nullseite has to give way to the zeropage.

The king is dead, long live the king!

I started my private blog Nullseite BOY 2008. Since then it experienced two rebrushes and got an accompanying offspring EOY 2015 – the zeropage. There is only so much spare time one can spent on blogging (and other stuff;-) so I decided to quit trying to curate two blogs at the same time. The Nullseite will diminish as I am in the process of migrating the most worthy Nullseite-Posts to the zeropage. This requires some tedious manual labour and will, thus, take some time. Stay tuned!

How to run Netgear ProSafe Utility on MacOS

No CommentsMacOS, The Tinkererby Axel Dietrich

Netgear does not offer a Mac-Version for their ProSafe Plus Utility. Since it doesn't run reliably with Wine, you'll have to use virtualizers like Parallels or VirtualBox.

Netgear is offering his switch management software “ProSafe Plus” for Windows. And for Windows only. Well, they just might have not noticed that there is at least one other very popular operating system in the market. Such things happen.

To still run ProSafe on a Mac and avoid the overhead involved by installing hardware virtualizing suits like “Parallels Desktop” or “VirtualBox”, I tried to use the compatibility layer software WINE to run ProSafe.

WINE

WINE requires XQuartz first, then Wine for MacOS can be installed. After that you can right click an arbitrary Windoze *.exe file and “open with…” Wine. Unfortunately, the ProSafe Plus Utility did not install smoothly. Had to restart the installation process a couple of times but could start the ProSafe Utility only once. Digging into Wine’s website winehq.org you will find that other users already reported about problems with the installation of ProSafe. To sum it up: No easy way this time. Let’s do it the hard way.

VirtualBox

The hard way means that you will have to use a hardware virtualizer like VirtualBox or Parallels Desktop. And, apparently, you will need Windoze. Luckily, I had an old Windoze 7 installation CD lying around. The first step is to install the free virtualizer VirtualBox by Oracle. The installation process is pretty straightforward and to just run the ProSafe Utility you should be fine with the standard settings suggested by the installer.

You will, most likely, have assigned an ISO-Image of your copy of Windoze during installation. After VirtualBox has been installed, start the Windoze Virtual Machine and get your copy of Windoze installed in the Virtual Machine. That might take some time. After successful installation of Windoze you can reboot, log into your Windoze account and install Netgear’s ProSafe Utility.

After installation of the ProSafe Utility fire it up and, if all went well, you might see a screen similar to the following one. The ProSafe utility scans the network and will list all discovered switches. My switch, a GS108PEv3, hast been found and I am, finally and after all that hassle, ready to configure the switch.

Nightlight Late-Night Edition

6 Comments3D Printing, Arduino, The Hackerer, The Tinkererby Axel Dietrich

A 3D printable night light with Arduino-controlled LED light effects and a virtually arbitrary number of front designs (limited only by your creativity).

This project powers electronic components (5V) with a mains supply circuit (230V > 5V) that is connected to a power plug (230V). If you are going to build this, make sure that you know what you do. In case of doubt, consult a skilled person that is familiar with mains voltage or use a safe power source like a line adapter or batteries.

tl;dr A nightlight based on a reworked Thingiverse design with Arduino-controlled LED light effects, touch sensors, and a piezo buzzer humming the first notes from the Imperial march. Watch the video to see it in action. Detailed instructions start below video.

Bragging rights

The rocket nightlight was presented in the German MAKE magazine 06/2016 as a community project. Thank you! 🙂

The link or a click on the picture take you to the table of contents of issue 06/2016. If you have questions concerning this project do not hesitate to contact me! <foobar@zeropage.io>

Project Description

You can find a great design for a LED nightlight with various emblems or logos like Stormtrooper, Superman, Punisher, etc. on Thingiverse. This design is based on a 3D printed case with a transparent and extruded inlay of the emblem/logo in the lid. The case has a hole on the backside to have an external power supply feed the internal light source, e.g., an RGB light stripe or similar.

I reworked this design to create a nightlight that

does not need an external power supply, i.e., has a plug and can be directly plugged into a wall socket
has touch switches to easily adjust the brightness, light effects (or modes), colors etc.
uses a piezo buzzer to acknowledge touch switch triggers and to play the first notes from the Imperial March when plugged into a socket (a little annoying, but can be switched off;-)
utilizes a mounting platform for six RGB LEDs that can be easily inserted into the case
fixes some minor issues in the original design (displaced inlay and mounting hole)
comes with a variety of light effects like fixed colors, strobe, or cyclone chase

Payload

1 x Arduino Pro Mini 5V 16MHz // Merchants on eBay offer a plethora of pro minis. Take care when ordering: The pro mini is available as 3,3V and 5V as well as 8MHz and 16MHz versions. Moreover: Many vendors are located in China; shipping may take a long time to your home country.
1 x Piezo buzzer // One of these (eBay) should work.
1 x Power supply // I used this EMSA050120, 5 V-/1,2 A from Pollin to harvest the mains supply circuit and the plug.
4 x 3D printed part // These parts comprise a case, an LED holder, a plate (or lid) and an emblem/logo. You will find the 3D templates as STL files on Thingiverse.
6 x RGB LED // The WS2812b have a nice color range and are usually cheapest when bought as an LED stripe. I had some spare LEDs from another project. You can order them on eBay or here (1m stripe, Roboter Bausatz Shop).
4 x M5, 16mm counter-sunk screw
1 x Software // The software for the Arduino is available in my Nightlight Late-Night Edition repository on GitHub.

Moreover a Dremel or similar to cut open the mains adapter, pliers, rasps, wires, some metal splints for the touch sensors, and, of course, a soldering iron.

Nightlight 3D Parts

The nightlight consists of four 3D printed parts; cf. the sandwich picture showing the different layers.

From bottom to top: 1) Case to host the mains supply circuit, Arduino pro mini, piezo buzzer, LEDs, touch switches, cables, and the plug. 2) LED holder. 3) The top plate and 4) the extruded emblem inlay.

3D Part 1: The Case

The case from the original design was only 13mm high (inner height) and, thus, not tall enough to host the electronic parts. I had to import the STL file into SketchUp and stretch the case on the z-axis to an inner height of 25mm. That gave me just enough space to squeeze the LED holder above the mains supply circuit into the case and still have 2 or 3mm distance from the top plate. The more space you have between the LEDs and the plate, the better the light will be diffused. But I did not want the nightlight to be more bulky than necessary so 25mm inner height had to suffice.

Increasing the height was the easy part. Designing the plug holder on the backside of the case was more difficult. I first measured the dimensions of the plug as precise as possible, then started to design a plug holder with SketchUp.

It took a couple of iterations and an according number of test prints until, finally, the plug snapped into the plug holder with a satisfying “click”. The plug fits so tight that I consider it to be unremovable without destroying the case. And I may add that this is by design since we are dealing with 230V AC power and the nightlight must be impenetrable by adventurous kid’s hands.

The case was printed with black REC PLA at 210°, bed temperature 60°, no support, 0.16mm height, 1.2mm wall thickness, and 66% infill. It depends on your 3D printer’s bridging abilities if the plug holder will be ok without support. If unsure, print the case with support turned on.

3D Part 2: The LED Holder

I wanted the LEDs in the nightlight to be on a planar surface to get an even illumination. The idea was to construct an LED holder in SketchUp that tightly fits into the case without gluing, is rather stable, and has legs to stand on. The images show what I came up with.

Luckily, the LED holder nearly immediately matched all of the above mentioned criteria. I chose white innofil3D PLA for the print since a white background looked best behind the semi-transparent inlay.

3D Part 3: The top Plate

The plate was printed with black REC PLA and the same print parameters as for the case (210°, bed temperature 60°, no support, 0.16mm height, 1.2mm wall thickness) except that infill was set to 100%. I did not want any light to escape through the plate. With a proper number of top and bottom layers 100% infill with black PLA might be an extreme overkill but I played it safe.

With 100% infill the plate came out rock solid which has another advantage: Some parts might need to be sanded so that the extruded emblem/logo wil fit into the plate. The more solid your parts, the better they can be sanded.

3D Part 4: The Emblem/Logo

The extruded rocket inlay was printed with transparent innofil3D PLA. You will notice that “transparent” is in no way comparable to acrylic glass or alike. Moreover, parts printed with this PLA look yellowed; like they have been exposed for too long in the sun. Nonetheless, this kind of transparency is the best you can get with current fused deposition modelling (FDM) based desktop 3D printers and PLA. Nylon and other filament materials might yield better results but they are more difficult to print and handle.
Infill was set to 22%. You will see the honeycomb pattern, or whatever type of infill you chose in your slicer, with such a low infill value. But more infill also means losing transparency. I was fine with 22%.

Avengers assemble!

Let’s put the hardware together.

Complete the Plate

The transparent emblem/logo has to be merged with the plate. Depending on the design there might be a couple of “loose” parts from the plate print that need to be inserted into the emblem/logo first. Rasps and sanding paper are your best friend in this step since the parts will most likely not fit straight off the 3D printer. While 3D prints are usually pretty nice, there are limits to the precision you can expect from FDM prints. The rocket has only one loose part which is the round window. That one is pretty easy to insert. If not, rasp and apply mild force. Do not apply too much pressure to the small parts – they might break or damage the plate. If in doubt, sand more and re-try often. It will finally fit. If all loose parts are pushed in the emblem/logo you will want to merge the emblem/logo with the plate. That might need some sanding too. The small and tall middle wing of the rocket will most likely need some sanding. Be very careful since it can break off easily. Carefully push the transparent part into the plate. A vise or a hammer might come in handy, depending on how brave you are. This step requires patience.

Disassemble the Power Supply

As mentioned in the Payload-section I used a very cheap EMSA050120 power supply from Pollin to harvest the mains supply circuit and the plug. The case turned out to be very intractable and successfully resisted my attempts to pry it open it with a screw driver or pliers. I could have tried to pop it open in the vise but did not want to risk damaging the PCB/electronics inside. Well, let’s mill it open – Dremel time!

Caveat: Always mill with safety glasses and use protective gloves. The picture is just for demonstration purposes. Milling plastic produces foul-smelling, and most likely toxic, fumes. Do it outdoors. The picture in the middle shows the mains supply circuit along with the plug. In the next picture you can see the backside of the supply circuit with the big L- and N-conductance pads on the right-hand side of the PCB.

Solder Wires on Plug

The plug will be connected with solid copper cables to the L- and N-conductance pads of the mains supply circuit.

There is an ongoing discussion whether 230V connections ought to be crimped or if they are allowed to be soldered. If you decide to solder make sure that a) the soldered parts are perfectly solder joined and b) voltage isolation in terms of the dielectric strength of the used materials, creepage and clearance has been considered properly.

Before we can solder the cables two small plastic bars have to be removed from the plug. I use pliers to simply break them off. After that I start to solder the cables on the plug’s connection pads (to the left and right of the middle screw). Or I tried because this turns out to be an epic soldering fail. I try a dozen times but can’t get the, sorry, GODDAMMIT cables to solder-join with the pads. The pads literally refuse to be soldered! But resistance is futile and a couple of search engine queries later I seem to be wiser: The pads are made of stainless steel which is pretty hard to solder with normal tin-solder. If not impossible at all. What I need is soldering fluid, something like this (Conrad).

If you read the soldering fluid’s hazard notes, well, you do not really want to use this stuff: Serious chemical burns of skin and eyes, irritating to the respiratory system, and so on and so forth. Zinc chloride is no fun. Keep away from children! After some more failed attempts even with the soldering fluid I learned that the pads need much more heat to join forces with the cables than I was used from soldering usual electronics stuff. So, finally, I got two nice solder joints. FTW!

Drill Holes for Touch Sensors

It is always a good idea to think before you act. And I wish I’d done that before printing the case since I forgot to add two 4mm holes for the touch sensors on the right-hand side of the case! Facepalm! Printing the case again just because two holes were missing was not an option. But we are not only apt with additive but also with subtractive manufacturing: I drill the holes with a 3mm wood drill and get a perfect diameter after some minor rasping. PLA is fairly easy to drill, e.g. compared to acrylic glass. But you may have to lift the drill from time to time to remove excess plastic. Wood drills are designed to automatically forward the excess wood to the top of the drill and out of the drill hole. When you drill PLA or other plastic materials it tends to melt and get stuck on the drill. The slower you drill, the better. Applying some drops of water or sewing-machine oil is said to help (not tried so far).

Connect Mains Supply Circuit to Plug

In this step we connect the mains supply circuit to the plug and fix the circuit in the case.

Voltage isolation: As already mentioned you will have to take care of proper voltage isolation when dealing with 230V. The pictures show how I did it but they do not claim to be a blueprint for proper electronic handling especially with respect to mains voltage isolation. I would suggest to use spacers to attach the mains supply circuit to the bottom of the case so nothing on the flipside of the PCB can touch the case. Moreover the whole mains supply circuit including the soldered wires should be isolated from the rest of the electronic parts which can easily be achieved by enclosing it with an additional 3D part. As always: In case of doubt, ask an expert!

First pop the plug into the case’s plug holder. Since the copper wires are pretty rigid it is a good idea to shorten and bend them properly before soldering the wires to the mains supply circuit.

Solder the mains supply circuit’s L-conductance pad to the brown copper wire. Repeat with the N-conductance pad and the blue wire. Finally, attach the mains supply circuit to the bottom of the case. You can see the black and red 5V power supply cables on the left-hand side of the mains supply circuit. We will use these later to power the LEDs and the Arduino microcontroller.

Attach LEDs to LED Holder

I decided to use six WS2812b LEDs and arranged them on the holder in a pattern that showed the most even illumination level during my tests. In case you’re a Lumen junkie there is enough room to cramp more LEDs on the holder. The LED strips usually come with sticky tape on their backside so gluing them on the holder is easy. After that I used 0.15mm enamelled copper wire to solder the connections between the +5V, GND and DOut->DIn pads. Keep the soldering time short to avoid melting the LED holder! The enamelled copper wire is a little tricky to solder because of the enamel coating. I suggest to first remove the enamel, e.g., by applying some tin solder, and then solder the wire to the LED pads. It’s more difficult the other way round. BTW: There is really no need to use enamelled copper wire. It looks nice but using them was more about aesthetics than function. Moreover, the enamelled copper tends to break at the solder joints. I recommend litz wire with a small diameter – easier to solder, less risk of breakage, same function.

Prepare the Touch Sensors

This nightlight requires two touch sensors to control its various functions. The Arduino library ADCTouch makes it very easy to add touch sensors to a project. You can connect nearly everything that changes its capacity when touched to an arbitrary analogue pin of the microcontroller and have that thing act like a touch sensor. In this project I use two small metal splints that will be stuck and glued in the drilled holes on the right-hand side of the case. To connect the splints to the Arduino I have to solder wires to them. Since they are made of stainless steel, I have to use soldering fluid again. One drop on each splint, plenty of heat, a little tin solder, and some heat shrink tubing later the two touch sensors are ready.

Wire it up!

The Fritzing breadboard view shows how the electronic components are wired up to the Arduino pro mini.

You can choose different pins on the Arduino by adjusting the Arduino Sketch accordingly.

+5V from the power mains supply circuit goes to the VCC pin while ground is connected to the GND pin on the Arduino.
The piezo buzzer’s negative pole is connected to the GND pin, the positive pole to pin 12.
The upper touch sensor goes to pin A0.
The lower touch sensor goes to pin A2.
The view shows symbolically only one LED, not the wiring of all six LEDs. The first LED’s Din is connected via a 220 Ohm resistor to pin 10. It is usually advised to use a resistor to cover power spikes that could harm the LEDs. VSS or +5V on the LED is connected to the VCC pin on the Arduino. VDD or ground on the LED is wired to the a GND pin.

That’s how it looks like when all components have been soldered and put into place in the case.

Regarding voltage isolation: The 5V and 230V components should be properly isolated from each other. An additional layer that encloses the mains supply circuit and separates the 230V wires from the rest of the circuit is currently work in progress.

I used hot glue to paste the Arduino and the piezo buzzer on the case. The touch sensors were easier to attach with super glue.

Light and Diffusion

We need to diffuse the light that is emitted by the LEDs so that the transparent rocket is evenly illuminated. I already had some experience with diffusion materials from another project where I tried normal paper with different grammages, frosted acrylic glass, and Ripstop. The results were ok, but not perfect. I followed a hint that white baking paper yields good diffusion results. Unfortunately, I was not able to find white baking paper; only the usual brown one. Next I tried sandwich paper (sic!) and that’s what I found to work best when it comes to LED light diffusion. Of course, it depends on what you are building and especially, how much space there is between the LEDs and the material of the boundary layer. Try different materials and find the one that best suits your needs. However, I like the sandwich paper and, thus, taped a double layer on the backside of the plate. After that, the plate is screwed to the case with four black M5x16mm counter-sunk screws. I wanted screws with no imprint on the screw head but did not pay (enough) attention to the seller’s pictures on eBay. So, always take a very close look at what you intend to buy. 😉 NB: The screws have to cut their way through the holes in the case so it can get tedious to get them in. Use appropriate force. Moreover, the screw heads were bigger than expected so I had to widen the reception holes on the lid’s front side with a hand countersink.

Code is Poetry

All that hardware does not do anything without the proper software. We need a sketch (aka program) for the Arduino pro mini so the nightlight will do the things described in the project description. Two of the used libraries are worth mentioning: The awesome FastLED library to control the RGB LEDs. And the ADCTouch library to easily turn a cable or a splint into a touch sensor. The sketch makes use of the Arduino’s inbuild non-volatile EEPROM to store modes, colors, and other stuff that can be reloaded the next time the nighlight is powered up. The most complicated part of the code is handling the touch sensors. Both sensors react to short (1st function), middle-long (2nd function) and long touches (3rd function) and trigger different functions depending on the touch durations. Sounds complicated, but is not. Or is it?

Upper sensor

Short touch. Increase brightness of LEDs until maximum is reached (17 steps). Then turn LEDs off.
Middle-long touch. Immediately return brightness to lowest setting, i.e., one step above zero.
Long touch. Toggle playing Imperial March on power-up on/off.

Lower sensor

Short touch. Change color, speed, or whatever of current lighting mode.
Middle-long touch. Switch to next light mode.
Long touch. Immediately switch to first light mode, i.e., fixed color.

You can find the code in my Nightlight Late-Night Edition repository on GitHub.

//
// Nightlight Late-Night Edition v1.3
// Copyright (C) 2016 Axel Dietrich <foobar@zeropage.io>
// http://zeropage.io
//
// An Arduino controlled nightlight with WS2812b RGB LEDs,
// touch sensor switches, a potpourri of nice lighting effects and a
// quite ugly piezo Star Wars(R) intro.
//
// This program is free software: you can redistribute it and/or modify it
// under the terms of the GNU General Public License as published by the Free
// Software Foundation, either version 3 of the License, or (at your option)
// any later version. This program is distributed in the hope that it will be
// useful, but WITHOUT ANY WARRANTY; without even the implied warranty of
// MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the GNU General
// Public License for more details. You should have received a copy of the GNU
// General Public License along with this program (file LICENSE). If not, see
// <http://www.gnu.org/licenses/>.
//
// History
// 1.3, 12.11.2016
//   - Added new mode eWHITE that switches all LEDs to, yes, white.
// 1.2, 13.09.2016
//   - eSTROBE: Using EVERY_N_MILLISECONDS macro did not work. Rolled my own.
//   - Very long touching mode button did not work. Used wrong variable names. Fixed.
//   - eBREATH mode looks ugly on lower brightness settings. Changed amplitude.
// 1.1, 12.09.2016
//   - Usability: increase sensor 2nd function waiting time. one second is too short and might induce unwanted triggers.
//   - Usability: add 4 sec long touch (3rd function) for mode sensor to quickly jump to first mode.
//   - Removed unnecessary code from eBREATHE mode.
// 1.0, 11.09.2016
//   - Initial release.
//
#include <FastLED.h>            // http://fastled.io/
#include <Streaming.h>          // http://arduiniana.org/libraries/streaming/
#include <ADCTouch.h>           // http://playground.arduino.cc/Code/ADCTouch
#include <EEPROM.h>

#define LED_DATA_PIN                                    10
#define LED_NUM_LEDS                                     6
#define LED_BRIGHTNESS_STEP_SIZE                        15
#define LED_COLOR_STEP_SIZE                              5
#define PIEZO_PIN                                       12
#define TSENSOR_BRIGHTNESS_PIN                          A0
#define TSENSOR_MODE_PIN                                A2
#define TSENSOR_BRIGHTNESS_2ND_FUNCTION_WAITING_TIME  1200 // in milliseconds
#define TSENSOR_BRIGHTNESS_3RD_FUNCTION_WAITING_TIME  3000 // in milliseconds
#define TSENSOR_MODE_2ND_FUNCTION_WAITING_TIME        1200 // in milliseconds
#define TSENSOR_MODE_3RD_FUNCTION_WAITING_TIME        3000 // in milliseconds
#define EEPROM_ADR_PLAY_IMPERIAL_MARCH                   0
#define EEPROM_ADR_MASTER_BRIGHTNESS                     1
#define EEPROM_ADR_MODE                                  2
#define EEPROM_ADR_FIXED_COLOR_INDEX                     3
#define EEPROM_ADR_TWINKLES_PALETTE                      4
#define EEPROM_ADR_STROBE_SPEED                          5
#define EEPROM_ADR_RAINBOW_DELTA_HUE                     6
#define EEPROM_ADR_RAINBOW_GLITTER_DELTA_HUE             7
#define EEPROM_ADR_CONFETTI_CHANCE                       8
#define EEPROM_ADR_BEATS_PER_MINUTE                      9
#define EEPROM_ADR_BREATHE_COLOR_INDEX                  10
#define EEPROM_ADR_CYCLONE_COLOR_INDEX                  11
#define IMPERIAL_MARCH_SPEED                           2.5 // higher value = play faster
#define ARRAY_SIZE(A)         (sizeof(A) / sizeof((A)[0]))
#define DEBUG                                            0
CRGB gLED[ LED_NUM_LEDS ];
CRGBPalette16 myPal = RainbowColors_p;
enum          gModes            { eSTART_MODE, eFIXED_COLOR, eCOLOR_TWINKLES, eSTROBE, eRAINBOW, eRAINBOW_WITH_GLITTER, eCONFETTI, eBPM, eBREATHE, eCYCLONE, eWHITE, eEND_MODE };
enum          gPiezoModes       { eBRIGHTNESS_PIEZO, eMODE_PIEZO, e3RD_FUNC_PIEZO };
uint16_t      gTouchBrightnessRef;
uint16_t      gTouchModeRef;
bool          gPlayImperialMarch       = true;
uint8_t       gMasterBrightness        = 120;
uint8_t       gCurrentMode             = eFIXED_COLOR;
uint8_t       gFixedColorIndex         = 0;
uint8_t       gTwinklesPalette         = 0;
uint8_t       gStrobeSpeed             = 100;
uint8_t       gRainbowDeltaHue         = 7;
uint8_t       gRainbowGlitterDeltaHue  = 7;
uint8_t       gConfettiChance          = 80;
uint8_t       gBeatsPerMinute          = 60;
uint8_t       gBreatheColorIndex       = 0;
uint8_t       gCycloneColorIndex       = 0;
uint8_t       gHue                     = 0;
bool          gPowerUp                 = true;

//
// forward declarations
void fPiezoShortTouch( byte mode );
void fPiezoLongTouch( byte mode );

void setup( ) {
  if ( DEBUG ) {
    delay( 500 );
    Serial.begin( 9600 );
    Serial.setTimeout( 200 ); // 200ms should be enough
  }
  randomSeed( analogRead( 1 ) );
  pinMode( PIEZO_PIN, OUTPUT );

  // Fetch data from EEPROM
  gPlayImperialMarch       = EEPROM.read( EEPROM_ADR_PLAY_IMPERIAL_MARCH );
  if(gPlayImperialMarch<0||gPlayImperialMarch>1)
    gPlayImperialMarch = true;
  gMasterBrightness        = EEPROM.read( EEPROM_ADR_MASTER_BRIGHTNESS );
  gCurrentMode             = EEPROM.read( EEPROM_ADR_MODE              );
  if ( gCurrentMode<(eSTART_MODE+1) || gCurrentMode>(eEND_MODE-1) )
    gCurrentMode = eSTART_MODE + 1;
  gFixedColorIndex         = EEPROM.read( EEPROM_ADR_FIXED_COLOR_INDEX         ); // for eFIXED_COLOR
  gTwinklesPalette         = EEPROM.read( EEPROM_ADR_TWINKLES_PALETTE          ); // for eCOLOR_TWINKLES
  gStrobeSpeed             = EEPROM.read( EEPROM_ADR_STROBE_SPEED              ); // for eSTROBE
  gRainbowDeltaHue         = EEPROM.read( EEPROM_ADR_RAINBOW_DELTA_HUE         ); // for eRAINBOW
  gRainbowGlitterDeltaHue  = EEPROM.read( EEPROM_ADR_RAINBOW_GLITTER_DELTA_HUE ); // for eRAINBOW_WITH_GLITTER
  gConfettiChance          = EEPROM.read( EEPROM_ADR_CONFETTI_CHANCE           ); // for eCONFETTI
  gBeatsPerMinute          = EEPROM.read( EEPROM_ADR_BEATS_PER_MINUTE          ); // for eBPM
  gBreatheColorIndex       = EEPROM.read( EEPROM_ADR_BREATHE_COLOR_INDEX       ); // for eBREATHE
  gCycloneColorIndex       = EEPROM.read( EEPROM_ADR_CYCLONE_COLOR_INDEX       ); // for eCYCLONE
  fChoosePalette( gTwinklesPalette );

  // FastLED setup
  FastLED.addLeds< WS2812B, LED_DATA_PIN, GRB >( gLED, LED_NUM_LEDS );
  FastLED.setCorrection( TypicalLEDStrip );
  FastLED.setBrightness( 0 );
  fill_solid( gLED, LED_NUM_LEDS, CRGB::Black );
  FastLED.show( );

  if ( gPlayImperialMarch )
    fPlayImperialMarch( );

  // Touch wire setup. Create reference values to account for the capacitance of control wires.
  gTouchBrightnessRef = ADCTouch.read( TSENSOR_BRIGHTNESS_PIN, 500 );
  gTouchModeRef       = ADCTouch.read( TSENSOR_MODE_PIN,       500 );

  // Welcome to the pleasure dome!
  if ( DEBUG ) {
    Serial << endl << endl << F( "Welcome to Nightlight Late-Night Edition v1.3" ) << endl;
    Serial << F( "(C) 2016 Axel Dietrich <foobar@zeropage.io>" ) << endl;
    Serial << F( "Type h for a list of commands." ) << endl;
  }
}

void loop( ) {
  static uint16_t lastMillisBrightness        = millis( );
  static uint16_t lastMillisMode              = millis( );
  static bool     touchedBrightness           = false;
  static bool     touchedMode                 = false;
  static bool     mustReleaseBrightnessSensor = false;
  static bool     mustReleaseModeSensor       = false;
         bool     shortModeTouch              = false;

  // Check if touch sensors have been activated.
  // Get Touch values.
  int touchBrightnessVal = ADCTouch.read( TSENSOR_BRIGHTNESS_PIN );
  int touchModeVal       = ADCTouch.read( TSENSOR_MODE_PIN       );

  // Remove offset computed in setup()
  touchBrightnessVal -= gTouchBrightnessRef;
  touchModeVal       -= gTouchModeRef;

  // Touch too much?
  // Check the BRIGHTNESS touch sensor.
  // short touch     => increase brightness by LED_BRIGHTNESS_STEP_SIZE
  // long touch      => set brightness to lowest value (i.e. night mode)
  // very long touch => toggle playing imperial march on boot
  if ( touchBrightnessVal > 40 ) {
    if ( !touchedBrightness )
      touchedBrightness = true;
    // Check if touch sensor touched for at least TSENSOR_BRIGHTNESS_2ND_FUNCTION_WAITING_TIME milliseconds.
    uint16_t m = millis( );
    if ( !mustReleaseBrightnessSensor ) {
      if ( ( m - lastMillisBrightness ) > TSENSOR_BRIGHTNESS_2ND_FUNCTION_WAITING_TIME ) {
        // a long touch => set brightnes to lowest value
        lastMillisBrightness = m;
        gMasterBrightness = 10;
        FastLED.setBrightness( gMasterBrightness );
        FastLED.show( );
        EEPROM.write( EEPROM_ADR_MASTER_BRIGHTNESS, gMasterBrightness );
        fPiezoLongTouch( eBRIGHTNESS_PIEZO );
        mustReleaseBrightnessSensor = true;
      }
    } else if ( ( m - lastMillisBrightness ) > TSENSOR_BRIGHTNESS_3RD_FUNCTION_WAITING_TIME ) {
      // a very long touch => toggle playing imperial march
      lastMillisBrightness = m;
      EEPROM.write( EEPROM_ADR_PLAY_IMPERIAL_MARCH, ( gPlayImperialMarch ? 0 : 1 ) );
      fPiezoLongTouch( e3RD_FUNC_PIEZO );
    }
  } else {
    if ( touchedBrightness ) {
      // We get here when brightness touch sensor was touched and released.
      touchedBrightness = false;
      if ( mustReleaseBrightnessSensor ) {
        // ah, brightness touch sensor released after a long touch
        mustReleaseBrightnessSensor = false;
      } else {
        // a short touch => gradually increase brightness
        gMasterBrightness = ( (gMasterBrightness + LED_BRIGHTNESS_STEP_SIZE) > 255 ? 0 : (gMasterBrightness + LED_BRIGHTNESS_STEP_SIZE) );
        FastLED.setBrightness( gMasterBrightness );
        FastLED.show( );
        EEPROM.write( EEPROM_ADR_MASTER_BRIGHTNESS, gMasterBrightness );
        if ( gMasterBrightness == (255-LED_BRIGHTNESS_STEP_SIZE) )
          fPiezoShortTouch( eBRIGHTNESS_PIEZO );
        if ( gMasterBrightness == 255 )
          fPiezoShortTouch( eBRIGHTNESS_PIEZO ), fPiezoShortTouch( eBRIGHTNESS_PIEZO );
        fPiezoShortTouch( eBRIGHTNESS_PIEZO );
      }
    }
    lastMillisBrightness = millis( );
  }

  // Touch too much?
  // Check the MODE touch sensor.
  // short touch     => function depends on mode
  // long touch      => switch to next mode
  // very long touch => jump to the first mode
  if ( touchModeVal > 40 ) {
    if ( !touchedMode )
      touchedMode = true;
    // Check if touch sensor touched for at least TSENSOR_MODE_2ND_FUNCTION_WAITING_TIME milliseconds.
    uint16_t m = millis( );
    if ( !mustReleaseModeSensor  ) {
      if ( ( m - lastMillisMode ) > TSENSOR_MODE_2ND_FUNCTION_WAITING_TIME ) {
        // a long touch => switch to the next mode
        byte noOfModes = eEND_MODE - eSTART_MODE - 1;
        gCurrentMode = ( gCurrentMode<noOfModes ? gCurrentMode+1 : eSTART_MODE+1 );
        lastMillisMode = m;
        mustReleaseModeSensor = true;
        fPiezoLongTouch( eMODE_PIEZO );
      }
    } else if ( ( m - lastMillisMode ) > TSENSOR_MODE_3RD_FUNCTION_WAITING_TIME ) {
      // a very long touch => jump to the first mode
      lastMillisMode = m;
      gCurrentMode = eSTART_MODE + 1;
      fPiezoLongTouch( e3RD_FUNC_PIEZO );
    }
  } else {
    if ( touchedMode ) {
      // We get here when mode touch sensor was touched and released.
      touchedMode = false;
      if ( mustReleaseModeSensor  ) {
        // ah, mode touch sensor released after a long touch
        mustReleaseModeSensor = false;
        EEPROM.write( EEPROM_ADR_MODE, gCurrentMode );
      } else {
        // a short touch => depends on mode what happens
        fPiezoShortTouch( eMODE_PIEZO );
        shortModeTouch = true;
      }
    }
    lastMillisMode = millis( );
  }

  switch ( gCurrentMode ) {
    case eFIXED_COLOR: {
        static bool firstTimeAfterBoot = true;
        if ( shortModeTouch ) {
          gFixedColorIndex = ( (gFixedColorIndex + LED_COLOR_STEP_SIZE) > 255 ? 0 : (gFixedColorIndex + LED_COLOR_STEP_SIZE) );
          fill_solid( gLED, LED_NUM_LEDS, ColorFromPalette( myPal, gFixedColorIndex ) );
          FastLED.show( );
          EEPROM.write( EEPROM_ADR_FIXED_COLOR_INDEX, gFixedColorIndex );
        }
        if (firstTimeAfterBoot||mustReleaseModeSensor) {
          fill_solid( gLED, LED_NUM_LEDS, ColorFromPalette( myPal, gFixedColorIndex ) );
          FastLED.show( );
          firstTimeAfterBoot = false;
        }
      }
      break;
    case eCOLOR_TWINKLES:
      if ( shortModeTouch ) {
        fNextPalette( );
        EEPROM.write( EEPROM_ADR_TWINKLES_PALETTE, gTwinklesPalette );
      }
      fTwinkle( );
      FastLED.show( );
      break;
    case eSTROBE: {
        static bool strobesSet = false;
        static uint16_t lastMillis = millis( );
        byte maxLEDsOn = ((int)(LED_NUM_LEDS/2)) + 1;
        gStrobeSpeed   = max( gStrobeSpeed, 10  );
        gStrobeSpeed   = min( gStrobeSpeed, 100 );
        if ( shortModeTouch ) {
          gStrobeSpeed = ( gStrobeSpeed>10 ? gStrobeSpeed-10 : 100 );
          EEPROM.write( EEPROM_ADR_STROBE_SPEED, gStrobeSpeed );
          Serial << "gStrobeSpeed " << gStrobeSpeed << endl;
        }
        if ( !strobesSet ) {
          for( byte i = 0; i < maxLEDsOn; i++ ) {
            gLED[ random( LED_NUM_LEDS ) ] = CRGB::White;
            FastLED.show( );
          }
          strobesSet = true;
        }
       // hm. EVERY_N_MILLISECONDS did not work here so have to roll my own.
        uint16_t m = millis( );
        if ( ( m - lastMillis ) > gStrobeSpeed ) {
          if ( strobesSet ) {
            fill_solid( gLED, LED_NUM_LEDS, CRGB::Black );
            strobesSet = false;
          }
          lastMillis = m;
        }
        FastLED.show( );
      }
      break;
    case eRAINBOW: {
        byte start    = 7;
        byte stepSize = 3;
        gRainbowDeltaHue = max( gRainbowDeltaHue, start );
        if ( shortModeTouch ) {
          gRainbowDeltaHue = ( gRainbowDeltaHue<(start+10*stepSize) ? gRainbowDeltaHue+stepSize : start );
          EEPROM.write( EEPROM_ADR_RAINBOW_DELTA_HUE, gRainbowDeltaHue );
        }
        fill_rainbow( gLED, LED_NUM_LEDS, gHue, gRainbowDeltaHue );
        FastLED.show( );
      }
      break;
    case eRAINBOW_WITH_GLITTER: {
        byte start    = 7;
        byte stepSize = 3;
        gRainbowGlitterDeltaHue = max( gRainbowGlitterDeltaHue, start );
        if ( shortModeTouch ) {
          gRainbowGlitterDeltaHue = ( gRainbowGlitterDeltaHue<(start+10*stepSize) ? gRainbowGlitterDeltaHue+stepSize : start );
          EEPROM.write( EEPROM_ADR_RAINBOW_GLITTER_DELTA_HUE, gRainbowGlitterDeltaHue );
        }
        fill_rainbow( gLED, LED_NUM_LEDS, gHue, gRainbowGlitterDeltaHue );
        if ( random8( ) < 80 ) // 30% chance of glitter
          gLED[ random16( LED_NUM_LEDS ) ] += CRGB::White;
        FastLED.show( );
      }
      break;
    case eCONFETTI: {
        byte start      = 80;
        byte stepSize   = 10;
        gConfettiChance = max( gConfettiChance, start );
        if ( shortModeTouch ) {
          gConfettiChance = ( gConfettiChance<(start+10*stepSize) ? gConfettiChance+stepSize : start );
          EEPROM.write( EEPROM_ADR_CONFETTI_CHANCE, gConfettiChance );
        }
        fadeToBlackBy( gLED, LED_NUM_LEDS, 10 );
        if ( random8( ) < gConfettiChance )
          gLED[ random16( LED_NUM_LEDS ) ] += CHSV( gHue + random8( 64 ), 200, 255 );
        FastLED.show( );
      }
      break;
    case eBPM: {
        byte startBeats = 60;
        byte stepSize   = 5;
        gBeatsPerMinute = max( gBeatsPerMinute, startBeats );
        gBeatsPerMinute = min( gBeatsPerMinute, startBeats+15*stepSize );
        if ( shortModeTouch ) {
          gBeatsPerMinute = ( gBeatsPerMinute<(startBeats+15*stepSize) ? gBeatsPerMinute+stepSize : startBeats );
          EEPROM.write( EEPROM_ADR_BEATS_PER_MINUTE, gBeatsPerMinute );
        }
        uint8_t beat = beatsin8( gBeatsPerMinute, 64, 255);
        for ( int i = 0; i < LED_NUM_LEDS; i++ )
          gLED[ i ] = ColorFromPalette( PartyColors_p, gHue+(i*2), beat-gHue+(i*10) );
        FastLED.show( );
      }
      break;
    case eBREATHE: {
        static byte counter = 0;
        if ( shortModeTouch ) {
          gBreatheColorIndex = ( (gBreatheColorIndex + LED_COLOR_STEP_SIZE) > 255 ? 0 : (gBreatheColorIndex + LED_COLOR_STEP_SIZE) );
          fill_solid( gLED, LED_NUM_LEDS, ColorFromPalette( myPal, gBreatheColorIndex ) );
          FastLED.show( );
          EEPROM.write( EEPROM_ADR_BREATHE_COLOR_INDEX, gBreatheColorIndex );
        }
        byte brightness = quadwave8( 3*(counter++) ); // quadwave8() is nearly a sine wave but 2/3 faster than sin8()
        fill_solid( gLED, LED_NUM_LEDS, ColorFromPalette( myPal, gBreatheColorIndex, brightness ) );
        FastLED.show( );
        if ( brightness > 254 )
          FastLED.delay( 50 );
      }
      break;
    case eCYCLONE: {
        static byte index = 0;
        if ( shortModeTouch ) {
          gCycloneColorIndex = ( (gCycloneColorIndex + LED_COLOR_STEP_SIZE) > 255 ? 0 : (gCycloneColorIndex + LED_COLOR_STEP_SIZE) );
          fill_solid( gLED, LED_NUM_LEDS, ColorFromPalette( myPal, gCycloneColorIndex ) );
          FastLED.show( );
          EEPROM.write( EEPROM_ADR_CYCLONE_COLOR_INDEX, gCycloneColorIndex );
        }
        EVERY_N_MILLISECONDS( 80 ) {
          gLED[ index ] = ColorFromPalette( myPal, gCycloneColorIndex );
          FastLED.show( );
          fadeToBlackBy( gLED, LED_NUM_LEDS, 50 );
          index = ( index < (LED_NUM_LEDS-1) ? index+1 : 0 );
        }
      }
      break;
    case eWHITE: {
        static bool firstTimeAfterBoot = true;
        if (firstTimeAfterBoot||mustReleaseModeSensor) {
          fill_solid( gLED, LED_NUM_LEDS, CRGB( 255, 255, 255 ) ); // set all LEDs to white
          FastLED.show( );
          firstTimeAfterBoot = false;
        }
      }
      break;
    default:
      break;
  }

  // slowly cycle the "base color" through the rainbow
  EVERY_N_MILLISECONDS( 20 ) { gHue++; }

  // fade in to master brightness when nightlight is plugged into socket.
  static byte fadeInBrightness = 0;
  if ( gPowerUp ) {
    if ( fadeInBrightness<gMasterBrightness ) {
      fadeInBrightness += 5;
      EVERY_N_MILLISECONDS( 10 ) {
        FastLED.setBrightness( fadeInBrightness );
        FastLED.show( );
      }
    } else
      gPowerUp = false;
  }

  // Check for serial command.
  if ( DEBUG ) {
    byte ch;
    if ( Serial.available( ) ) {
      switch ( ch = Serial.read( ) ) {
        case 'b': {
          // b{0..255} set brightness
          while ( !Serial.available( ) ) {}
          byte brightness = Serial.parseInt( );
          brightness = ( brightness > 255 ? 255 : brightness );
          FastLED.setBrightness( brightness );
          FastLED.show( );
          break;
        }
        case 'h':
          fShowHelp( );
          break;
        case 'p': {
          // p{0..255} set LEDs to color from palette myPal
          while ( !Serial.available( ) ) {}
          byte index = Serial.parseInt( );
          index = ( index > 255 ? 255 : index );
          fill_solid( gLED, LED_NUM_LEDS, ColorFromPalette( myPal, index ) );
          FastLED.show( );
          break;
        }
        case 'R':
          // soft reset, does not reset peripherals and registers
          asm volatile ("  jmp 0");
          break;
        default:
          // none
          break;
      }
    }
  } // EOF check for serial command
}

//
// Functions

//
// =====================================================================================
// Color twinkle lights by Mark Kriegsman.
//   https://gist.github.com/kriegsman/5408ecd397744ba0393e
#define STARTING_BRIGHTNESS 64
#define FADE_IN_SPEED       28
#define FADE_OUT_SPEED      20
#define DENSITY             128

CRGBPalette16 mkG_Palette;
CRGB r(CRGB::Red), R(0xA80016), w(85,85,85), W(CRGB::White), l(0xE1A024);
CRGBPalette16 mkG_allPalettes[] = {
  CRGBPalette16( r,r,r,r, R,R,R,R, r,r,r,r, R,R,R,R ),      // Red, Burgundy
  CRGBPalette16( l,l,l,l, l,l,l,l, l,l,l,l, l,l,l,l ),      // Incandescent "fairy lights"
  //LavaColors_p,
  ForestColors_p,
  CRGBPalette16( 0x000000, 0x250000, 0x4A0000, 0x6F0000,    // Variation of HeatColors_p with no white and less yellow
                 0x940000, 0xB90000, 0xDE0000, 0xFF0000,
                 0xFF2500, 0xFF4A00, 0xFF6F00, 0xFF9400,
                 0xFFB900, 0xFFDE00, 0xFFFF00, 0x250000 ),
  CRGBPalette16( W,W,W,W, w,w,w,w, w,w,w,w, w,w,w,w )       // Snow
};
void fChoosePalette( byte paletteNumber )
{
  paletteNumber = min( paletteNumber, ARRAY_SIZE(mkG_allPalettes)-1 ); // sanity check
  mkG_Palette = mkG_allPalettes[ paletteNumber ];
}
void fNextPalette( )
{
  gTwinklesPalette = ( gTwinklesPalette < (ARRAY_SIZE(mkG_allPalettes)-1) ? gTwinklesPalette+1 : 0 );
  fChoosePalette( gTwinklesPalette );
}

enum { eGETTING_DARKER = 0, eGETTING_BRIGHTER = 1 };
void fTwinkle( )
{
  // Make each pixel brighter or darker, depending on
  // its 'direction' flag.
  fBrightenOrDarkenEachPixel( FADE_IN_SPEED, FADE_OUT_SPEED) ;

  // Now consider adding a new random twinkle
  if( random8() < DENSITY ) {
    int pos = random16( LED_NUM_LEDS );
    if( !gLED[ pos ]) {
      gLED[pos] = ColorFromPalette( mkG_Palette, random8( ), STARTING_BRIGHTNESS, NOBLEND );
      fsetPixelDirection( pos, eGETTING_BRIGHTER );
    }
  }
}

void fBrightenOrDarkenEachPixel( fract8 fadeUpAmount, fract8 fadeDownAmount )
{
 for( uint16_t i = 0; i < LED_NUM_LEDS; i++) {
    if( fGetPixelDirection( i ) == eGETTING_DARKER ) {
      // This pixel is getting darker
      gLED[i] = fMakeDarker( gLED[i], fadeDownAmount );
    } else {
      // This pixel is getting brighter
      gLED[i] = fMakeBrighter( gLED[i], fadeUpAmount );
      // now check to see if we've maxxed out the brightness
      if( gLED[i].r == 255 || gLED[i].g == 255 || gLED[i].b == 255) {
        // if so, turn around and start getting darker
        fsetPixelDirection( i, eGETTING_DARKER );
      }
    }
  }
}

CRGB fMakeBrighter( const CRGB& color, fract8 howMuchBrighter )
{
  CRGB incrementalColor = color;
  incrementalColor.nscale8( howMuchBrighter );
  return color + incrementalColor;
}

CRGB fMakeDarker( const CRGB& color, fract8 howMuchDarker)
{
  CRGB newcolor = color;
  newcolor.nscale8( 255 - howMuchDarker );
  return newcolor;
}

uint8_t gDirectionFlags[ (LED_NUM_LEDS+7) / 8];
bool fGetPixelDirection( uint16_t i)
{
  uint16_t index = i / 8;
  uint8_t  bitNum = i & 0x07;
  return bitRead( gDirectionFlags[index], bitNum );
}

void fsetPixelDirection( uint16_t i, bool dir )
{
  uint16_t index = i / 8;
  uint8_t  bitNum = i & 0x07;
  bitWrite( gDirectionFlags[index], bitNum, dir);
}

//
// show help in serial monitor
void fShowHelp( ) {
  Serial << F( "=====================================================" ) << endl;
  Serial << F( "COMMANDS" ) << endl;
  Serial << F( "h                This help." ) << endl;
  Serial << F( "b{0..255}        Set LED master brightness." ) << endl;
  Serial << F( "p{0..255}        Set LEDs to color from (green,yellow,red) palette." ) << endl;
  Serial << F( "R                Reset Arduino. Does not reset peripherals and registers." ) << endl;
  Serial << F( "=====================================================" ) << endl;
}

//
// Bells'n'whistles! Play first notes from Star Wars Imperial March when the nightlight is plugged in.
// c/o https://gist.github.com/tagliati/1804108
void fPlayImperialMarch( )
{
  fBeep( 440, (long)(500/IMPERIAL_MARCH_SPEED) );
  fBeep( 440, (long)(500/IMPERIAL_MARCH_SPEED) );
  fBeep( 440, (long)(500/IMPERIAL_MARCH_SPEED) );
  fBeep( 349, (long)(350/IMPERIAL_MARCH_SPEED) );
  fBeep( 523, (long)(150/IMPERIAL_MARCH_SPEED) );
  fBeep( 440, (long)(500/IMPERIAL_MARCH_SPEED) );
  fBeep( 349, (long)(350/IMPERIAL_MARCH_SPEED) );
  fBeep( 523, (long)(150/IMPERIAL_MARCH_SPEED) );
  fBeep( 440, (long)(800/IMPERIAL_MARCH_SPEED) );
  delay( 100 );
  fBeep( 659, (long)(500/IMPERIAL_MARCH_SPEED) );
  fBeep( 659, (long)(500/IMPERIAL_MARCH_SPEED) );
  fBeep( 659, (long)(500/IMPERIAL_MARCH_SPEED) );
  fBeep( 698, (long)(350/IMPERIAL_MARCH_SPEED) );
  fBeep( 523, (long)(150/IMPERIAL_MARCH_SPEED) );
  fBeep( 415, (long)(500/IMPERIAL_MARCH_SPEED) );
  fBeep( 349, (long)(350/IMPERIAL_MARCH_SPEED) );
  fBeep( 523, (long)(150/IMPERIAL_MARCH_SPEED) );
  fBeep( 440, (long)(1000/IMPERIAL_MARCH_SPEED) );
}

//
// play a tone on piezo speaker with specific frequency and duration
void fBeep( int frequencyInHertz, long timeInMilliseconds )
{
  long delayAmount = (long)( 1000000 / frequencyInHertz );
  long loopTime    = (long)( ( timeInMilliseconds*1000 ) / ( delayAmount*2 ) );
  for ( int x = 0; x < loopTime; x++ ) {
    digitalWrite( PIEZO_PIN, HIGH );
    delayMicroseconds( delayAmount );
    digitalWrite( PIEZO_PIN, LOW );
    delayMicroseconds( delayAmount );
  }
  delay( 20 ); // a little delay to make all notes sound separate
}

//
// play this when one of the touch wire buttons is briefly touched
void fPiezoShortTouch( byte mode )
{
  int note = ( mode == eBRIGHTNESS_PIEZO ? 3000 : 1000 );
  fBeep( note, 2 );
}

//
// play this when one of the touch wire buttons is touched for a longer time (triggering its 2nd function)
void fPiezoLongTouch( byte mode )
{
  switch ( mode ) {
    case eBRIGHTNESS_PIEZO:
      fBeep( 240, 2 );
      fBeep( 880, 5 );
      fBeep( 1600, 9 );
      break;
    case eMODE_PIEZO:
      fBeep( 120, 2 );
      fBeep( 440, 5 );
      fBeep( 800, 9 );
      break;
    default:  /* e3RD_FUNC_PIEZO */
      fBeep( 5000, 15 );
      delay( 20 );
      fBeep( 5000, 15 );
      delay( 20 );
      fBeep( 5000, 15 );
      delay( 20 );
      fBeep( 5000, 15 );
      break;
  }
}

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

121

122

123

124

125

126

127

128

129

130

131

132

133

134

135

136

137

138

139

140

141

142

143

144

145

146

147

148

149

150

151

152

153

154

155

156

157

158

159

160

161

162

163

164

165

166

167

168

169

170

171

172

173

174

175

176

177

178

179

180

181

182

183

184

185

186

187

188

189

190

191

192

193

194

195

196

197

198

199

200

201

202

203

204

205

206

207

208

209

210

211

212

213

214

215

216

217

218

219

220

221

222

223

224

225

226

227

228

229

230

231

232

233

234

235

236

237

238

239

240

241

242

243

244

245

246

247

248

249

250

251

252

253

254

255

256

257

258

259

260

261

262

263

264

265

266

267

268

269

270

271

272

273

274

275

276

277

278

279

280

281

282

283

284

285

286

287

288

289

290

291

292

293

294

295

296

297

298

299

300

301

302

303

304

305

306

307

308

309

310

311

312

313

314

315

316

317

318

319

320

321

322

323

324

325

326

327

328

329

330

331

332

333

334

335

336

337

338

339

340

341

342

343

344

345

346

347

348

349

350

351

352

353

354

355

356

357

358

359

360

361

362

363

364

365

366

367

368

369

370

371

372

373

374

375

376

377

378

379

380

381

382

383

384

385

386

387

388

389

390

391

392

393

394

395

396

397

398

399

400

401

402

403

404

405

406

407

408

409

410

411

412

413

414

415

416

417

418

419

420

421

422

423

424

425

426

427

428

429

430

431

432

433

434

435

436

437

438

439

440

441

442

443

444

445

446

447

448

449

450

451

452

453

454

455

456

457

458

459

460

461

462

463

464

465

466

467

468

469

470

471

472

473

474

475

476

477

478

479

480

481

482

483

484

485

486

487

488

489

490

491

492

493

494

495

496

497

498

499

500

501

502

503

504

505

506

507

508

509

510

511

512

513

514

515

516

517

518

519

520

521

522

523

524

525

526

527

528

529

530

531

532

533

534

535

536

537

538

539

540

541

542

543

544

545

546

547

548

549

550

551

552

553

554

555

556

557

558

559

560

561

562

563

564

565

566

567

568

569

570

571

572

573

574

575

576

577

578

579

580

581

582

583

584

585

586

587

588

589

590

591

592

593

594

595

596

597

598

599

600

601

602

603

604

605

606

607

608

609

610

611

612

613

614

615

616

617

618

619

620

621

622

623

624

625

626

627

628

629

630

631

632

633

634

635

636

637

638

639

640

641

642

643

644

// Nightlight Late-Night Edition v1.3

// http://zeropage.io

// An Arduino controlled nightlight with WS2812b RGB LEDs,

// touch sensor switches, a potpourri of nice lighting effects and a

// quite ugly piezo Star Wars(R) intro.

// This program is free software: you can redistribute it and/or modify it

// under the terms of the GNU General Public License as published by the Free

// Software Foundation, either version 3 of the License, or (at your option)

// any later version. This program is distributed in the hope that it will be

// useful, but WITHOUT ANY WARRANTY; without even the implied warranty of

// MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General

// Public License for more details. You should have received a copy of the GNU

// General Public License along with this program (file LICENSE). If not, see

// <http://www.gnu.org/licenses/>.

// History

// 1.3, 12.11.2016

// - Added new mode eWHITE that switches all LEDs to, yes, white.

// 1.2, 13.09.2016

// - eSTROBE: Using EVERY_N_MILLISECONDS macro did not work. Rolled my own.

// - Very long touching mode button did not work. Used wrong variable names. Fixed.

// - eBREATH mode looks ugly on lower brightness settings. Changed amplitude.

// 1.1, 12.09.2016

// - Usability: increase sensor 2nd function waiting time. one second is too short and might induce unwanted triggers.

// - Usability: add 4 sec long touch (3rd function) for mode sensor to quickly jump to first mode.

// - Removed unnecessary code from eBREATHE mode.

// 1.0, 11.09.2016

// - Initial release.

#include <FastLED.h> // http://fastled.io/

#include <Streaming.h> // http://arduiniana.org/libraries/streaming/

#include <ADCTouch.h> // http://playground.arduino.cc/Code/ADCTouch

#include <EEPROM.h>

#define LED_DATA_PIN 10

#define LED_NUM_LEDS 6

#define LED_BRIGHTNESS_STEP_SIZE 15

#define LED_COLOR_STEP_SIZE 5

#define PIEZO_PIN 12

#define TSENSOR_BRIGHTNESS_PIN A0

#define TSENSOR_MODE_PIN A2

#define TSENSOR_BRIGHTNESS_2ND_FUNCTION_WAITING_TIME 1200 // in milliseconds

#define TSENSOR_BRIGHTNESS_3RD_FUNCTION_WAITING_TIME 3000 // in milliseconds

#define TSENSOR_MODE_2ND_FUNCTION_WAITING_TIME 1200 // in milliseconds

#define TSENSOR_MODE_3RD_FUNCTION_WAITING_TIME 3000 // in milliseconds

#define EEPROM_ADR_PLAY_IMPERIAL_MARCH 0

#define EEPROM_ADR_MASTER_BRIGHTNESS 1

#define EEPROM_ADR_MODE 2

#define EEPROM_ADR_FIXED_COLOR_INDEX 3

#define EEPROM_ADR_TWINKLES_PALETTE 4

#define EEPROM_ADR_STROBE_SPEED 5

#define EEPROM_ADR_RAINBOW_DELTA_HUE 6

#define EEPROM_ADR_RAINBOW_GLITTER_DELTA_HUE 7

#define EEPROM_ADR_CONFETTI_CHANCE 8

#define EEPROM_ADR_BEATS_PER_MINUTE 9

#define EEPROM_ADR_BREATHE_COLOR_INDEX 10

#define EEPROM_ADR_CYCLONE_COLOR_INDEX 11

#define IMPERIAL_MARCH_SPEED 2.5 // higher value = play faster

#define ARRAY_SIZE(A) (sizeof(A) / sizeof((A)[0]))

#define DEBUG 0

CRGB gLED[ LED_NUM_LEDS ];

CRGBPalette16 myPal = RainbowColors_p;

enum gModes { eSTART_MODE, eFIXED_COLOR, eCOLOR_TWINKLES, eSTROBE, eRAINBOW, eRAINBOW_WITH_GLITTER, eCONFETTI, eBPM, eBREATHE, eCYCLONE, eWHITE, eEND_MODE };

enum gPiezoModes { eBRIGHTNESS_PIEZO, eMODE_PIEZO, e3RD_FUNC_PIEZO };

uint16_t gTouchBrightnessRef;

uint16_t gTouchModeRef;

bool gPlayImperialMarch = true;

uint8_t gMasterBrightness = 120;

uint8_t gCurrentMode = eFIXED_COLOR;

uint8_t gFixedColorIndex = 0;

uint8_t gTwinklesPalette = 0;

uint8_t gStrobeSpeed = 100;

uint8_t gRainbowDeltaHue = 7;

uint8_t gRainbowGlitterDeltaHue = 7;

uint8_t gConfettiChance = 80;

uint8_t gBeatsPerMinute = 60;

uint8_t gBreatheColorIndex = 0;

uint8_t gCycloneColorIndex = 0;

uint8_t gHue = 0;

bool gPowerUp = true;

// forward declarations

void fPiezoShortTouch( byte mode );

void fPiezoLongTouch( byte mode );

void setup( ) {

if ( DEBUG ) {

delay( 500 );

Serial.begin( 9600 );

Serial.setTimeout( 200 ); // 200ms should be enough

}

randomSeed( analogRead( 1 ) );

pinMode( PIEZO_PIN, OUTPUT );

// Fetch data from EEPROM

gPlayImperialMarch = EEPROM.read( EEPROM_ADR_PLAY_IMPERIAL_MARCH );

if(gPlayImperialMarch<0||gPlayImperialMarch>1)

gPlayImperialMarch = true;

gMasterBrightness = EEPROM.read( EEPROM_ADR_MASTER_BRIGHTNESS );

gCurrentMode = EEPROM.read( EEPROM_ADR_MODE );

if ( gCurrentMode<(eSTART_MODE+1) || gCurrentMode>(eEND_MODE-1) )

gCurrentMode = eSTART_MODE + 1;

gFixedColorIndex = EEPROM.read( EEPROM_ADR_FIXED_COLOR_INDEX ); // for eFIXED_COLOR

gTwinklesPalette = EEPROM.read( EEPROM_ADR_TWINKLES_PALETTE ); // for eCOLOR_TWINKLES

gStrobeSpeed = EEPROM.read( EEPROM_ADR_STROBE_SPEED ); // for eSTROBE

gRainbowDeltaHue = EEPROM.read( EEPROM_ADR_RAINBOW_DELTA_HUE ); // for eRAINBOW

gRainbowGlitterDeltaHue = EEPROM.read( EEPROM_ADR_RAINBOW_GLITTER_DELTA_HUE ); // for eRAINBOW_WITH_GLITTER

gConfettiChance = EEPROM.read( EEPROM_ADR_CONFETTI_CHANCE ); // for eCONFETTI

gBeatsPerMinute = EEPROM.read( EEPROM_ADR_BEATS_PER_MINUTE ); // for eBPM

gBreatheColorIndex = EEPROM.read( EEPROM_ADR_BREATHE_COLOR_INDEX ); // for eBREATHE

gCycloneColorIndex = EEPROM.read( EEPROM_ADR_CYCLONE_COLOR_INDEX ); // for eCYCLONE

fChoosePalette( gTwinklesPalette );

// FastLED setup

FastLED.addLeds< WS2812B, LED_DATA_PIN, GRB >( gLED, LED_NUM_LEDS );

FastLED.setCorrection( TypicalLEDStrip );

FastLED.setBrightness( 0 );

fill_solid( gLED, LED_NUM_LEDS, CRGB::Black );

FastLED.show( );

if ( gPlayImperialMarch )

fPlayImperialMarch( );

// Touch wire setup. Create reference values to account for the capacitance of control wires.

gTouchBrightnessRef = ADCTouch.read( TSENSOR_BRIGHTNESS_PIN, 500 );

gTouchModeRef = ADCTouch.read( TSENSOR_MODE_PIN, 500 );

// Welcome to the pleasure dome!

if ( DEBUG ) {

Serial << endl << endl << F( "Welcome to Nightlight Late-Night Edition v1.3" ) << endl;

Serial << F( "Type h for a list of commands." ) << endl;

}

void loop( ) {

static uint16_t lastMillisBrightness = millis( );

static uint16_t lastMillisMode = millis( );

static bool touchedBrightness = false;

static bool touchedMode = false;

static bool mustReleaseBrightnessSensor = false;

static bool mustReleaseModeSensor = false;

bool shortModeTouch = false;

// Check if touch sensors have been activated.

// Get Touch values.

int touchBrightnessVal = ADCTouch.read( TSENSOR_BRIGHTNESS_PIN );

int touchModeVal = ADCTouch.read( TSENSOR_MODE_PIN );

// Remove offset computed in setup()

touchBrightnessVal -= gTouchBrightnessRef;

touchModeVal -= gTouchModeRef;

// Touch too much?

// Check the BRIGHTNESS touch sensor.

// short touch => increase brightness by LED_BRIGHTNESS_STEP_SIZE

// long touch => set brightness to lowest value (i.e. night mode)

// very long touch => toggle playing imperial march on boot

if ( touchBrightnessVal > 40 ) {

if ( !touchedBrightness )

touchedBrightness = true;

// Check if touch sensor touched for at least TSENSOR_BRIGHTNESS_2ND_FUNCTION_WAITING_TIME milliseconds.

uint16_t m = millis( );

if ( !mustReleaseBrightnessSensor ) {

if ( ( m - lastMillisBrightness ) > TSENSOR_BRIGHTNESS_2ND_FUNCTION_WAITING_TIME ) {

// a long touch => set brightnes to lowest value

lastMillisBrightness = m;

gMasterBrightness = 10;

FastLED.setBrightness( gMasterBrightness );

FastLED.show( );

EEPROM.write( EEPROM_ADR_MASTER_BRIGHTNESS, gMasterBrightness );

fPiezoLongTouch( eBRIGHTNESS_PIEZO );

mustReleaseBrightnessSensor = true;

}

} else if ( ( m - lastMillisBrightness ) > TSENSOR_BRIGHTNESS_3RD_FUNCTION_WAITING_TIME ) {

// a very long touch => toggle playing imperial march

lastMillisBrightness = m;

EEPROM.write( EEPROM_ADR_PLAY_IMPERIAL_MARCH, ( gPlayImperialMarch ? 0 : 1 ) );

fPiezoLongTouch( e3RD_FUNC_PIEZO );

}

} else {

if ( touchedBrightness ) {

// We get here when brightness touch sensor was touched and released.

touchedBrightness = false;

if ( mustReleaseBrightnessSensor ) {

// ah, brightness touch sensor released after a long touch

mustReleaseBrightnessSensor = false;

} else {

// a short touch => gradually increase brightness

gMasterBrightness = ( (gMasterBrightness + LED_BRIGHTNESS_STEP_SIZE) > 255 ? 0 : (gMasterBrightness + LED_BRIGHTNESS_STEP_SIZE) );

FastLED.setBrightness( gMasterBrightness );

FastLED.show( );

EEPROM.write( EEPROM_ADR_MASTER_BRIGHTNESS, gMasterBrightness );

if ( gMasterBrightness == (255-LED_BRIGHTNESS_STEP_SIZE) )

fPiezoShortTouch( eBRIGHTNESS_PIEZO );

if ( gMasterBrightness == 255 )

fPiezoShortTouch( eBRIGHTNESS_PIEZO ), fPiezoShortTouch( eBRIGHTNESS_PIEZO );

fPiezoShortTouch( eBRIGHTNESS_PIEZO );

}

lastMillisBrightness = millis( );

}

// Touch too much?

// Check the MODE touch sensor.

// short touch => function depends on mode

// long touch => switch to next mode

// very long touch => jump to the first mode

if ( touchModeVal > 40 ) {

if ( !touchedMode )

touchedMode = true;

// Check if touch sensor touched for at least TSENSOR_MODE_2ND_FUNCTION_WAITING_TIME milliseconds.

uint16_t m = millis( );

if ( !mustReleaseModeSensor ) {

if ( ( m - lastMillisMode ) > TSENSOR_MODE_2ND_FUNCTION_WAITING_TIME ) {

// a long touch => switch to the next mode

byte noOfModes = eEND_MODE - eSTART_MODE - 1;

gCurrentMode = ( gCurrentMode<noOfModes ? gCurrentMode+1 : eSTART_MODE+1 );

lastMillisMode = m;

mustReleaseModeSensor = true;

fPiezoLongTouch( eMODE_PIEZO );

}

} else if ( ( m - lastMillisMode ) > TSENSOR_MODE_3RD_FUNCTION_WAITING_TIME ) {

// a very long touch => jump to the first mode

lastMillisMode = m;

gCurrentMode = eSTART_MODE + 1;

fPiezoLongTouch( e3RD_FUNC_PIEZO );

}

} else {

if ( touchedMode ) {

// We get here when mode touch sensor was touched and released.

touchedMode = false;

if ( mustReleaseModeSensor ) {

// ah, mode touch sensor released after a long touch

mustReleaseModeSensor = false;

EEPROM.write( EEPROM_ADR_MODE, gCurrentMode );

} else {

// a short touch => depends on mode what happens

fPiezoShortTouch( eMODE_PIEZO );

shortModeTouch = true;

}

lastMillisMode = millis( );

}

switch ( gCurrentMode ) {

case eFIXED_COLOR: {

static bool firstTimeAfterBoot = true;

if ( shortModeTouch ) {

gFixedColorIndex = ( (gFixedColorIndex + LED_COLOR_STEP_SIZE) > 255 ? 0 : (gFixedColorIndex + LED_COLOR_STEP_SIZE) );

fill_solid( gLED, LED_NUM_LEDS, ColorFromPalette( myPal, gFixedColorIndex ) );

FastLED.show( );

EEPROM.write( EEPROM_ADR_FIXED_COLOR_INDEX, gFixedColorIndex );

}

if (firstTimeAfterBoot||mustReleaseModeSensor) {

fill_solid( gLED, LED_NUM_LEDS, ColorFromPalette( myPal, gFixedColorIndex ) );

FastLED.show( );

firstTimeAfterBoot = false;

}

break;

case eCOLOR_TWINKLES:

if ( shortModeTouch ) {

fNextPalette( );

EEPROM.write( EEPROM_ADR_TWINKLES_PALETTE, gTwinklesPalette );

}

fTwinkle( );

FastLED.show( );

break;

case eSTROBE: {

static bool strobesSet = false;

static uint16_t lastMillis = millis( );

byte maxLEDsOn = ((int)(LED_NUM_LEDS/2)) + 1;

gStrobeSpeed = max( gStrobeSpeed, 10 );

gStrobeSpeed = min( gStrobeSpeed, 100 );

if ( shortModeTouch ) {

gStrobeSpeed = ( gStrobeSpeed>10 ? gStrobeSpeed-10 : 100 );

EEPROM.write( EEPROM_ADR_STROBE_SPEED, gStrobeSpeed );

Serial << "gStrobeSpeed " << gStrobeSpeed << endl;

}

if ( !strobesSet ) {

for( byte i = 0; i < maxLEDsOn; i++ ) {

gLED[ random( LED_NUM_LEDS ) ] = CRGB::White;

FastLED.show( );

}

strobesSet = true;

}

// hm. EVERY_N_MILLISECONDS did not work here so have to roll my own.

uint16_t m = millis( );

if ( ( m - lastMillis ) > gStrobeSpeed ) {

if ( strobesSet ) {

fill_solid( gLED, LED_NUM_LEDS, CRGB::Black );

strobesSet = false;

}

lastMillis = m;

}

FastLED.show( );

}

break;

case eRAINBOW: {

byte start = 7;

byte stepSize = 3;

gRainbowDeltaHue = max( gRainbowDeltaHue, start );

if ( shortModeTouch ) {

gRainbowDeltaHue = ( gRainbowDeltaHue<(start+10*stepSize) ? gRainbowDeltaHue+stepSize : start );

EEPROM.write( EEPROM_ADR_RAINBOW_DELTA_HUE, gRainbowDeltaHue );

}

fill_rainbow( gLED, LED_NUM_LEDS, gHue, gRainbowDeltaHue );

FastLED.show( );

}

break;

case eRAINBOW_WITH_GLITTER: {

byte start = 7;

byte stepSize = 3;

gRainbowGlitterDeltaHue = max( gRainbowGlitterDeltaHue, start );

if ( shortModeTouch ) {

gRainbowGlitterDeltaHue = ( gRainbowGlitterDeltaHue<(start+10*stepSize) ? gRainbowGlitterDeltaHue+stepSize : start );

EEPROM.write( EEPROM_ADR_RAINBOW_GLITTER_DELTA_HUE, gRainbowGlitterDeltaHue );

}

fill_rainbow( gLED, LED_NUM_LEDS, gHue, gRainbowGlitterDeltaHue );

if ( random8( ) < 80 ) // 30% chance of glitter

gLED[ random16( LED_NUM_LEDS ) ] += CRGB::White;

FastLED.show( );

}

break;

case eCONFETTI: {

byte start = 80;

byte stepSize = 10;

gConfettiChance = max( gConfettiChance, start );

if ( shortModeTouch ) {

gConfettiChance = ( gConfettiChance<(start+10*stepSize) ? gConfettiChance+stepSize : start );

EEPROM.write( EEPROM_ADR_CONFETTI_CHANCE, gConfettiChance );

}

fadeToBlackBy( gLED, LED_NUM_LEDS, 10 );

if ( random8( ) < gConfettiChance )

gLED[ random16( LED_NUM_LEDS ) ] += CHSV( gHue + random8( 64 ), 200, 255 );

FastLED.show( );

}

break;

case eBPM: {

byte startBeats = 60;

byte stepSize = 5;

gBeatsPerMinute = max( gBeatsPerMinute, startBeats );

gBeatsPerMinute = min( gBeatsPerMinute, startBeats+15*stepSize );

if ( shortModeTouch ) {

gBeatsPerMinute = ( gBeatsPerMinute<(startBeats+15*stepSize) ? gBeatsPerMinute+stepSize : startBeats );

EEPROM.write( EEPROM_ADR_BEATS_PER_MINUTE, gBeatsPerMinute );

}

uint8_t beat = beatsin8( gBeatsPerMinute, 64, 255);

for ( int i = 0; i < LED_NUM_LEDS; i++ )

gLED[ i ] = ColorFromPalette( PartyColors_p, gHue+(i*2), beat-gHue+(i*10) );

FastLED.show( );

}

break;

case eBREATHE: {

static byte counter = 0;

if ( shortModeTouch ) {

gBreatheColorIndex = ( (gBreatheColorIndex + LED_COLOR_STEP_SIZE) > 255 ? 0 : (gBreatheColorIndex + LED_COLOR_STEP_SIZE) );

fill_solid( gLED, LED_NUM_LEDS, ColorFromPalette( myPal, gBreatheColorIndex ) );

FastLED.show( );

EEPROM.write( EEPROM_ADR_BREATHE_COLOR_INDEX, gBreatheColorIndex );

}

byte brightness = quadwave8( 3*(counter++) ); // quadwave8() is nearly a sine wave but 2/3 faster than sin8()

fill_solid( gLED, LED_NUM_LEDS, ColorFromPalette( myPal, gBreatheColorIndex, brightness ) );

FastLED.show( );

if ( brightness > 254 )

FastLED.delay( 50 );

}

break;

case eCYCLONE: {

static byte index = 0;

if ( shortModeTouch ) {

gCycloneColorIndex = ( (gCycloneColorIndex + LED_COLOR_STEP_SIZE) > 255 ? 0 : (gCycloneColorIndex + LED_COLOR_STEP_SIZE) );

fill_solid( gLED, LED_NUM_LEDS, ColorFromPalette( myPal, gCycloneColorIndex ) );

FastLED.show( );

EEPROM.write( EEPROM_ADR_CYCLONE_COLOR_INDEX, gCycloneColorIndex );

}

EVERY_N_MILLISECONDS( 80 ) {

gLED[ index ] = ColorFromPalette( myPal, gCycloneColorIndex );

FastLED.show( );

fadeToBlackBy( gLED, LED_NUM_LEDS, 50 );

index = ( index < (LED_NUM_LEDS-1) ? index+1 : 0 );

}

break;

case eWHITE: {

static bool firstTimeAfterBoot = true;

if (firstTimeAfterBoot||mustReleaseModeSensor) {

fill_solid( gLED, LED_NUM_LEDS, CRGB( 255, 255, 255 ) ); // set all LEDs to white

FastLED.show( );

firstTimeAfterBoot = false;

}

break;

default:

break;

}

// slowly cycle the "base color" through the rainbow

EVERY_N_MILLISECONDS( 20 ) { gHue++; }

// fade in to master brightness when nightlight is plugged into socket.

static byte fadeInBrightness = 0;

if ( gPowerUp ) {

if ( fadeInBrightness<gMasterBrightness ) {

fadeInBrightness += 5;

EVERY_N_MILLISECONDS( 10 ) {

FastLED.setBrightness( fadeInBrightness );

FastLED.show( );

}

} else

gPowerUp = false;

}

// Check for serial command.

if ( DEBUG ) {

byte ch;

if ( Serial.available( ) ) {

switch ( ch = Serial.read( ) ) {

case 'b': {

// b{0..255} set brightness

while ( !Serial.available( ) ) {}

byte brightness = Serial.parseInt( );

brightness = ( brightness > 255 ? 255 : brightness );

FastLED.setBrightness( brightness );

FastLED.show( );

break;

}

case 'h':

fShowHelp( );

break;

case 'p': {

// p{0..255} set LEDs to color from palette myPal

while ( !Serial.available( ) ) {}

byte index = Serial.parseInt( );

index = ( index > 255 ? 255 : index );

fill_solid( gLED, LED_NUM_LEDS, ColorFromPalette( myPal, index ) );

FastLED.show( );

break;

}

case 'R':

// soft reset, does not reset peripherals and registers

asm volatile (" jmp 0");

break;

default:

// none

break;

}

} // EOF check for serial command

}

// Functions

// =====================================================================================

// Color twinkle lights by Mark Kriegsman.

// https://gist.github.com/kriegsman/5408ecd397744ba0393e

#define STARTING_BRIGHTNESS 64

#define FADE_IN_SPEED 28

#define FADE_OUT_SPEED 20

#define DENSITY 128

CRGBPalette16 mkG_Palette;

CRGB r(CRGB::Red), R(0xA80016), w(85,85,85), W(CRGB::White), l(0xE1A024);

CRGBPalette16 mkG_allPalettes[] = {

CRGBPalette16( r,r,r,r, R,R,R,R, r,r,r,r, R,R,R,R ), // Red, Burgundy

CRGBPalette16( l,l,l,l, l,l,l,l, l,l,l,l, l,l,l,l ), // Incandescent "fairy lights"

//LavaColors_p,

ForestColors_p,

CRGBPalette16( 0x000000, 0x250000, 0x4A0000, 0x6F0000, // Variation of HeatColors_p with no white and less yellow

0x940000, 0xB90000, 0xDE0000, 0xFF0000,

0xFF2500, 0xFF4A00, 0xFF6F00, 0xFF9400,

0xFFB900, 0xFFDE00, 0xFFFF00, 0x250000 ),

CRGBPalette16( W,W,W,W, w,w,w,w, w,w,w,w, w,w,w,w ) // Snow

};

void fChoosePalette( byte paletteNumber )

{

paletteNumber = min( paletteNumber, ARRAY_SIZE(mkG_allPalettes)-1 ); // sanity check

mkG_Palette = mkG_allPalettes[ paletteNumber ];

}

void fNextPalette( )

{

gTwinklesPalette = ( gTwinklesPalette < (ARRAY_SIZE(mkG_allPalettes)-1) ? gTwinklesPalette+1 : 0 );

fChoosePalette( gTwinklesPalette );

}

enum { eGETTING_DARKER = 0, eGETTING_BRIGHTER = 1 };

void fTwinkle( )

{

// Make each pixel brighter or darker, depending on

// its 'direction' flag.

fBrightenOrDarkenEachPixel( FADE_IN_SPEED, FADE_OUT_SPEED) ;

// Now consider adding a new random twinkle

if( random8() < DENSITY ) {

int pos = random16( LED_NUM_LEDS );

if( !gLED[ pos ]) {

gLED[pos] = ColorFromPalette( mkG_Palette, random8( ), STARTING_BRIGHTNESS, NOBLEND );

fsetPixelDirection( pos, eGETTING_BRIGHTER );

}

void fBrightenOrDarkenEachPixel( fract8 fadeUpAmount, fract8 fadeDownAmount )

{

for( uint16_t i = 0; i < LED_NUM_LEDS; i++) {

if( fGetPixelDirection( i ) == eGETTING_DARKER ) {

// This pixel is getting darker

gLED[i] = fMakeDarker( gLED[i], fadeDownAmount );

} else {

// This pixel is getting brighter

gLED[i] = fMakeBrighter( gLED[i], fadeUpAmount );

// now check to see if we've maxxed out the brightness

if( gLED[i].r == 255 || gLED[i].g == 255 || gLED[i].b == 255) {

// if so, turn around and start getting darker

fsetPixelDirection( i, eGETTING_DARKER );

}

CRGB fMakeBrighter( const CRGB& color, fract8 howMuchBrighter )

{

CRGB incrementalColor = color;

incrementalColor.nscale8( howMuchBrighter );

return color + incrementalColor;

}

CRGB fMakeDarker( const CRGB& color, fract8 howMuchDarker)

{

CRGB newcolor = color;

newcolor.nscale8( 255 - howMuchDarker );

return newcolor;

}

uint8_t gDirectionFlags[ (LED_NUM_LEDS+7) / 8];

bool fGetPixelDirection( uint16_t i)

{

uint16_t index = i / 8;

uint8_t bitNum = i & 0x07;

return bitRead( gDirectionFlags[index], bitNum );

}

void fsetPixelDirection( uint16_t i, bool dir )

{

uint16_t index = i / 8;

uint8_t bitNum = i & 0x07;

bitWrite( gDirectionFlags[index], bitNum, dir);

}

// show help in serial monitor

void fShowHelp( ) {

Serial << F( "=====================================================" ) << endl;

Serial << F( "COMMANDS" ) << endl;

Serial << F( "h This help." ) << endl;

Serial << F( "b{0..255} Set LED master brightness." ) << endl;

Serial << F( "p{0..255} Set LEDs to color from (green,yellow,red) palette." ) << endl;

Serial << F( "R Reset Arduino. Does not reset peripherals and registers." ) << endl;

Serial << F( "=====================================================" ) << endl;

}

// Bells'n'whistles! Play first notes from Star Wars Imperial March when the nightlight is plugged in.

// c/o https://gist.github.com/tagliati/1804108

void fPlayImperialMarch( )

{

fBeep( 440, (long)(500/IMPERIAL_MARCH_SPEED) );

fBeep( 349, (long)(350/IMPERIAL_MARCH_SPEED) );

fBeep( 523, (long)(150/IMPERIAL_MARCH_SPEED) );

fBeep( 440, (long)(500/IMPERIAL_MARCH_SPEED) );

fBeep( 349, (long)(350/IMPERIAL_MARCH_SPEED) );

fBeep( 523, (long)(150/IMPERIAL_MARCH_SPEED) );

fBeep( 440, (long)(800/IMPERIAL_MARCH_SPEED) );

delay( 100 );

fBeep( 659, (long)(500/IMPERIAL_MARCH_SPEED) );

fBeep( 698, (long)(350/IMPERIAL_MARCH_SPEED) );

fBeep( 523, (long)(150/IMPERIAL_MARCH_SPEED) );

fBeep( 415, (long)(500/IMPERIAL_MARCH_SPEED) );

fBeep( 349, (long)(350/IMPERIAL_MARCH_SPEED) );

fBeep( 523, (long)(150/IMPERIAL_MARCH_SPEED) );

fBeep( 440, (long)(1000/IMPERIAL_MARCH_SPEED) );

}

// play a tone on piezo speaker with specific frequency and duration

void fBeep( int frequencyInHertz, long timeInMilliseconds )

{

long delayAmount = (long)( 1000000 / frequencyInHertz );

long loopTime = (long)( ( timeInMilliseconds*1000 ) / ( delayAmount*2 ) );

for ( int x = 0; x < loopTime; x++ ) {

digitalWrite( PIEZO_PIN, HIGH );

delayMicroseconds( delayAmount );

digitalWrite( PIEZO_PIN, LOW );

delayMicroseconds( delayAmount );

}

delay( 20 ); // a little delay to make all notes sound separate

}

// play this when one of the touch wire buttons is briefly touched

void fPiezoShortTouch( byte mode )

{

int note = ( mode == eBRIGHTNESS_PIEZO ? 3000 : 1000 );

fBeep( note, 2 );

}

// play this when one of the touch wire buttons is touched for a longer time (triggering its 2nd function)

void fPiezoLongTouch( byte mode )

{

switch ( mode ) {

case eBRIGHTNESS_PIEZO:

fBeep( 240, 2 );

fBeep( 880, 5 );

fBeep( 1600, 9 );

break;

case eMODE_PIEZO:

fBeep( 120, 2 );

fBeep( 440, 5 );

fBeep( 800, 9 );

break;

default: /* e3RD_FUNC_PIEZO */

fBeep( 5000, 15 );

delay( 20 );

fBeep( 5000, 15 );

delay( 20 );

fBeep( 5000, 15 );

delay( 20 );

fBeep( 5000, 15 );

break;

}

Ready Player One

That was a real fun project and the roket nightlight turned out to be a full success!

Sep 2016, i.f.

Lord Overhaul: How to fix a rake’s missing wing nut

No Comments3D Printing, Lord Overhaul, The Tinkererby Axel Dietrich

A lost wing nut is no reason to buy a new rake. Neither is an evil coarse pitched screw. Swap the screw, print a wing nut, and fix it!

Our rake lost its wing nut that is used to fix the pusher for the blades.

On first inspection I thought, that I just take any other M5 wing nut and that thing is good for another ten years of gardening service. But far wrong. The ISO metric screw threads (Wikipedia) come in different pitches: fine, middle, and coarse (at least in Germany). The thread in the rake must be either middle or coarse. At least none of my fine nuts fits on the thread.

So what now? Make or buy? Buy a couple of wing nuts? Buy a new rake? Of course not. Let’s replace the screw with a M5 fine pitched one.

First step: Pry open the lid. Done. Second step: Remove the old screw. Not an easy task since the manufacturer first drilled a hole and then pushed or hammered the screw through the hole so it stuck really, really tight. After a couple of miserable attempts to remove it with pliers I realized that there is only one appropriate tool for this job: A hammer. The evil screw is out.

Let’s see how we get the new screw attached to the lid. Soldering stainless steel is difficult. Welding would surely work but is somewhat impossible without weldering equipment. Last resort: Glue! Hot glue, not durable enough. The same might apply to super glue. But two-component power putty should be fine.

Funny thing: I do have nuts, but no wing nuts! Duh! So let’s print a wing nut using the awesome Ultimate Nut Knob Generator (Thingiverse) by wstein. Here it is.

I super glued a washer on the outer side so the PLA will not be squashed or damaged when the wing nut is tightened. Now it’s time to put the pieces back together.

Avengers assemble!

All set and done. Let the gardening begin!

Ultimaker 2+ Low Friction Spool Holder with Bearings

No Comments3D Printing, The Tinkererby Axel Dietrich

Stop squeaking, jamming, and under-extrusion! Use this Ultimaker low friction bearing based spool holder to cancel noises and add real Jesus gliding action!

The spool holder shipped with the Ultimaker2+ is ok and with the new extruder there should be no issues with underextrusion. Depending on the size and type of the filament spool you might encounter squeaking noises from time to time. Surely not serious enough an issue to substitute the spool holder. But what if a spool does not fit on the spool holder and gets completely jammed? That’s what exactly happened with a spool from REC. Time for a new spool holder!

sneakypoo designed a nice bearing based Low friction spool holder and put it on Thingiverse. Thank you! The spool holder requires five 3D printed parts together with two bearings, a threaded rod and a couple of nuts. It comes in two different lengths for big and not so big spools as well as two different diameters to either fit 626 or 608 bearings.

I printed the short 608 version which is sufficient for standard 750g filament spools. The holder is very well designed and everything fit perfectly. Except the spacer which was too long so I had to rasp it down by approximately 4-5mm. A couple of commenters already pointed that out on Thingiverse. So trust them (or me, or all of us) and shrink the spacer in your slicer prior to printing!

The following picture shows the order in which the parts have to be assembled.

The assembled spool holder.

And the new spool holder attached to the Ultimaker.

Check sneakypoo’s video to see what low friction looks like in real life. Awesome!

That thing is virtually noiseless and gives real Jesus gliding action. Luv it!

TopCraft Elektro-Tacker tackert wieder

No CommentsThe Tinkererby Axel Dietrich

Ein alter TopCraft-Tacker tat nicht mehr. Wenn man genügend viele Gene aus der Danger-Seeker-Sektion besitzt, kann man am Sicherheitskontakt rumpfuschen.

Liebe Kinder, unbedarfte Maker und leichtsinnige Bastler: Macht das hier beschriebene nicht! Niemals. Das ist nur eine Machbarkeitsstudie in kontrollierter Umgebung gewesen. Danach wurde das Gerät entsorgt. So ein Elektro-Tacker ist schon ohne diesen Eingriff ein gefährliches Elektrogerät. Mit einer solchen Modifikation könnt Ihr andere und Euch selbst ernsthaft verletzen!

Requisiten-Typ: “Hey Scrooge! Ich krieg’ das Geweih an der Maus nicht fest!”
Scrooge: “Hast du’s schonmal mit ‘nem Tacker versucht?”

Zur Sache: Der alte Voltcraft-Elektrotacker wollte nicht mehr so richtig. Nach kurzer Inspektion war der zu schwergängige Sicherheitskontakt am Tackernadel-Ausgang als Übeltäter identifiziert. Das Gerät schoss nur noch manchmal und ohne erkennbares Muster. Sehr nervig, wenn man 100 mal drücken muß, bis endlich eine Nadel rauskommt.

Erstmal aufschrauben und schauen, was sich da machen lässt. Ergebnis: Zu wenig mit überschaubarem Aufwand. Also kurzerhand den Sicherheitskontakt entfernt, Kabel zusammengelötet und Gerät zusammengeschraubt. Jetzt ist wieder jeder Schuß ein Treffer. Ach ja, hundsgefährlich ist das natürlich auch. Aber gut für die Zombie-Apokalypse geeignet (solange Strom in der Nähe ist).

Bitte den Sicherheitshinweis oben beachten!

Noise dampening feet for Ultimaker2

No Comments3D Printing, The Hackererby Axel Dietrich

Your Ultimaker is too noisy? Bring peace and harmony back in your living room with 3D printed noise dampening feet.

3D printers can be quite noisy. Besides a full encapsulation that might also proof valuable if printing ABS there are other ways to lower the volume. One is to reduce the vibration that is transferred from the moving parts of the printer to its case and from there to the table which resonates and, depending on size and material, is likely to subsequently work like a noise amplifier.

This effect can be reduced with noise dampening feet. There are a already lot of dampening feet designs available on Thingiverse or YouMagine so there is no need to design a new one. The Damping foot UM original by Kees de Ligt looks promising.

The first foot printed well with black REC filament using 0.15mm layer height, 0.8mm shell thickness, 35% infill, support, and with the square side facing the print bed. I use “hotter than normal” settings for the REC PLA: 215° noozle and 70° bed temperature. These temperatures provide nice prints and good platform adhesion with the REC filament. After that I got lightheaded and tried to print the remaining three feet all at the same time. While this is usually not a big deal, the REC PLA filament consistently turns out to be somewhat picky. Too much cooling time between the layers and the prints tend to fail.

This is how the three-at-the-same-time fail looks like.

Heavily warped edges on the bottom-most print. The first layers of the dampening foot in the middle look ok. But the top-most foot has been utterly destroyed. You’re on the lucky side if you notice such failures early enough to abort the print and, thus, avoid wasting material.

As I took a closer look at the dampening foot that was printed first, I realized that I would need two of the feet “as is” and another two feet mirrored at the y-axis. Only this way all four feet would face the same direction when attached to the printer. So, I should be thankful that the simultaneous print of three feet failed since that would have produced two unmirrored feet. You can easily mirror objects at all axes in Cura: Click the object then hit the mirror button on the bottom left and click on of the Mirror X/Y/Z buttons.

The remaining one foot as well as the y-mirrored two feet print like a charm. Attaching the feet is easy: Lift one corner of the printer and push the corresponding foot underneath this corner. Repeat with all other corners. Done.

[Update] There is definitely a damping effect resulting in a less noisy soundscape. Good! But after a couple of prints the two rear feet have been tightly compressed so the curvatures of the snake-like construct touch each other. Hence, the damping characteristics of the rear feet are lost. Reason: The 35% infill and 0.8mm outer shell thickness are to weak to support the heavy rear part of the Ultimaker. Solution: Using 1.2mm outer shell thickness and 90% infill yields a new “as is” rear-left foot, and a new y-mirrored rear-right foot that are of heavy duty quality and now easily support the Ultimaker’s rear side.
